Production facilities
We promise to provide the high precision and steady products by the result of manufacturing technology which we cultivated for many years since 1966.
Double column type machining center with five-face machining equipment, Complex CNC lathe machine, Machining center of long material, Mirror polishing machine, Grinding machine. And factory is kept constant temperature environment. We put together various facilities. We can accept for the production of many kinds in small quantities. We help customers by our production and sales system which we can follow absolutely user's requirements.
Kyushu factory : This factory can meet various demands as mass production factory of slide shafts.
| Cutting machine |
|---|
| ●High speed cutting machine |
Manufactured by ourselves |
1 |
| ●Automatic cutting machine |
Manufactured by ourselves |
1 |
| ●Manual cutting machine |
Manufactured by ourselves |
2 |
| ●Automatic band sawing machine |
NIKO TECH |
1 |
| ●Semi-automatic cutting machine |
|
1 |
| Machining department, Lathe machine |
|---|
| ●CNC lathe machine for long material |
KINWA Taiwan |
Φ660〜3435
|
2 |
| ●CNC lathe machine |
MORI SEIKI, MAZAK, TAKISAWA |
390×964 Others
|
11 |
| ●Numerical controlled high precision lathe machine |
TAKISAWA |
650×3000 Others |
6 |
| ●General purpose late machine |
TAKIASAWA, MAZAK, CHUBU |
650×2000 Others |
8 |
| ●Complex CNC lathe machine |
(INTEGREX) MAZAK |
φ75×350×1000 |
1 |
| |
(Multiplex) MAZAK |
φ35×1200 |
1 |
| Machining department, Milling machine |
|---|
| ●Double column type machining center with five-face machining equipment |
OKUMA |
2550×5000×1350 |
1 |
| ●Double column type machining center |
OKUMA |
1400×3000×1000 Others |
2 |
| ●Vertical type machining center |
OKUMA、MAZAK |
660×1530×610 Others |
4 |
| ●NC milling machine |
MITSUBISHI, SHIZUOKA |
800×500×500 Others |
3 |
| ●General purpose milling machine |
SHIZUOKA |
280×1100 Others |
4 |
| Horizontal boring machine |
TOSHIBA |
800×1000×700 |
1 |
| Special processing machines |
|---|
| ●Gun drill machine |
KOREA GUN DRILL |
φ32×2000 |
1 |
| ●Wire electric discharge machine |
SEIBU ELECTRIC & MACHINERY |
950×700×300 |
1 |
| Heat treatment department |
|---|
| ●High frequency oscillator |
JEOL |
150kw×60kHz |
1 |
| |
KONDO ELECTRONICS INDUSTRY |
100kw×150khz |
1 |
| ●Traverse movement hardening machine |
Manufactured by ourselves |
φ80×6000 |
1 |
| ●Small diameter horizontal movement hardening machine |
Manufactured by ourselves |
φ13×3000 |
1 |
| ●Vertical movement hardening machine |
Manufactured by ourselves |
φ200×2800 |
1 |
| ●Small diameter vertical movement hardening machine |
KONDO ELECTRONICS INDUSTRY |
φ20×1000 |
1 |
| ●Tempering furnace |
TAKEMOTO INDUSTRY ELECTRIC HEAT |
3200×1000×1000 |
2 |
| Grinding department |
|---|
●Internal cylindrical grinding machine
|
YAMADA KIKO, Hole diameter 8 to 200mm, Maximum length 200mm, 1 machine |
|
1 |
| ●External cylindrical grinding machine |
JTEKT, SHIGIYA MACHINERY WORKS, OKUMA |
φ200, 3000 Others |
8 |
| ●Center less grinding machine |
MICRON MACHINERY, OHMIYTA MACHINERY |
φ80×6000 Others |
6 |
| ●CNC grinding machine |
JTEKT, OKUMA, OKAMOTO |
φ200×1500 Others |
3 |
| ●Center less grinding machine (Buffing) |
NIPPON KENMAKI |
φ6 〜 φ60 |
1 |
| Inspection equipment |
|---|
●Wet type magnaflux inspection equipment
|
TOYO JIKI INDUSTRY |
1 |
●Hand type magnaflux inspection equipment
|
TOYO JIKI INDUSTRY |
1 |
●Rockwell hardness tester
|
FUTURE-TECH CORP
|
3 |
| ●Shore hardness tester |
NAKAI PRECISION MACHINERY MFG. |
2 |
●Micro-vickers tester
|
FUTURE-TECH CORP |
1 |
●Digital length measuring
|
Manufactured by ourselves |
1 |
●Surface roughness measuring instrument
|
MITUTOYO |
1 |
●Three dimensions measuring instrument
|
MITUTOYO |
1 |
| ●Projector |
MITUTOYO 2550×5000×1350 |
1 |
| Straightening |
|---|
●Oil hydraulic press
|
MANABE |
Various 1 |
| ●Manual press |
Manufactured by ourselves |
4 |
| |
|
|
| Production control system |
|---|
●Production control system
|
Placement in whole branches and factories, Manufactured by ourselves |
1 |
Fukushima factory, The factory of base point for further technology advancement of YSK
| Cutting machine |
|---|
| ●Manual cutting machine |
Manufactured by ourselves |
1 |
| ●Semi-automatic cutting machine |
|
1 |
| ●Band sawing |
AMADA |
1 |
| Machining department, Lathe machine |
|---|
| ●CNC lathe machine for long material |
TAIWAN KINWA |
φ900 × 6310 Others |
2 |
| ●CNC lathe machine |
MORI SEIKI |
φ420 × 570 Others |
2 |
| ●Numerical control precision lathe machine |
TAKISAWA |
650 × 4000 Others |
5 |
| ●General purpose late machine |
TAKISAWA, MAZAK, MORI SEIKI |
600 × 1500 Others |
9 |
| Machining department, Milling machine |
|---|
| ●Double column type machining center |
OKUMA |
1530 × 660× 610 |
2 |
| ●NC milling machine |
OKUMA |
300 × 1000 |
1 |
| ●General purpose milling machine |
SHIZUOKA, YAMAZAKI |
300 × 1500 Others |
3 |
| ●Horizontal boring |
AOYAMA TEKKOSHO |
1100 × 1300 × 1400 |
1 |
| Heat treatment department |
|---|
| ●High frequency oscillator |
FUJI ELECTRONICS INDUSTRY |
5kHz×600kw/50kHz×340kw
SWITCHING-TYPE |
1 |
| ●Vertical movement induction hardening |
Manufactured by ourselves |
Φ20〜φ200 × 4000 |
1 |
| ●Horizontal movement induction hardening |
Auto system |
φ16〜 80×3000 |
1 |
| ●Tempering furnace |
TAKASAGO INDUSTRY |
4000 × 1000 × 1000 |
1 |
| Grinding department |
|---|
●CNC cylindrical grinding
|
SHIGIYA MACHINERY WORKS |
φ430×5000 Others |
2 |
●Cylindrical grinding
|
JTEKT |
φ420×3200 Others |
3 |
| ●Center-less grinding |
MICRON MACHINERY, OHMIYA MACHINERY |
φ80×3000 Others |
4 |
●Mirror polishing
|
MIRAC CORPORATION |
φ200×4000 |
1 |
| ●Center hole grinding |
TAKATA |
1000 |
1 |
| Inspection equipment |
|---|
| ●Rockwell hardness tester |
FUTURE-TECH CORP. |
2 |
●Shore hardness tester
|
NAKAI PRECISION MACHINERY MFG. |
1 |
●Micro-Vickers tester
|
FUTURE-TECH CORP. |
1 |
| ●Simple surface roughness tester |
TAYLOR HOBSON |
1 |
●Roundness measuring
|
TAYLOR HOBSON |
1 |
| ●Shore hardness tester |
KEYENCE |
1 |
| ●Texture microscope |
MITUTOYO |
1 |
| Straightening machines |
|---|
●Oil hydraulic press
|
OSAKA JACK |
600〜3000kN |
1 |
●Oil hydraulic press
|
ATSUGI, TOWA SEIKI
|
（30ｔ、15ｔ） |
Various 1 |
| ●Manual press |
Manufactured by ourselves |
1 |
Osaka factory, The Osaka factory is smallest and offers the largest service in YSK.
| Cutting machine |
|---|
| ●Manual cutting machine |
Manufactured by ourselves |
2 |
| ●Metal saw |
AMADA |
1 |
| Machining department, Lathe machine |
|---|
| ●CNC lathe machine |
OKUMA |
φ300 × 500 Others |
2 |
| ●General purpose high precision lathe |
TAKISAWA |
φ200 × 1500 Others |
2 |
| ●General purpose lathe |
TAKISAWA |
φ200 × 1500 Others |
4 |
| Machining department, Milling machine |
|---|
| ●General purpose milling |
SHIZUOKA MACHINE TOOL |
200 × 700 |
2 |
| ●Bench drilling |
YOSHIDA TEKKOSHO |
|
1 |
| ●Vertical machining center |
OKUMA |
560 × 460 × 460 |
1 |
| Grinding department |
|---|
●Center-less grinding
|
OHMIYA SEISAKUSHO |
φ50 × 1000
|
1 |
| ●Cylindrical grinding |
JTEKT, SHIGIYA MACHINERY WORKS |
φ200 × 2000 Others |
2 |
| Straightening machines |
|---|
●Manual press
|
Manufactured by ourselves |
1 |
| Inspection equipment |
|---|
| ●Rockwell hardness tester |
NAKAI PRECISION MACHINERY MFG. |
1 |
●Shore hardness tester
|
NAKAI PRECISION MACHINERY MFG. |
1 |
●Surface roughness tester
|
TOKYO SEIMITSU |
1 |
| ●Projector |
MITUTOYO |
1 |
